Specifications

Description

Equipment • FIREWALL FORWARD o TITAN® 340CC Engine, 180HP o Magnesium Accessory Case o Spin-On Oil Filter & Vernatherm o Perforated Fuel Nozzle o Adjustable Cowl Flaps o CATTO Composite Propeller o Dynamic prop balancing o Lightweight 40 amp alternator o Dual Electronic Ignition o Ignition backup battery system o Iridium spark plugs o Lightweight Hartzell Starter o Carburetor heat • FUEL SYSTEM o Two 20 gallon wing tanks (40 gallon capacity) – Extended Fuel Tanks (6 Inspection Covers) o Fuel selector valve (Left, Right, Off, & Both) o Gravity feed fuel system o No header tanks or fuel pump o Fuel sight gauge in wing roots o Fuel filter and drain o Primer • WINGS & TAIL o Super Cub airfoil – USA35(B) o Wings tested to 1,865 lbs o (40% higher than LSA requirements) o Flaps – Three positions: 15°/30°/50° o Vortex generators o Aerodynamically balanced tail feathers o Gap Seals • AIRFRAME o Complete 4130 reinforced fuselage tested to 1,865 lbs o (40% higher than LSA requirements) o Carbon fiber components o Extended Baggage Compartment & Access Door o Front fuel step on landing gear • AVIONICS o Garmin G3X Touch System o GDU 465 Touch Screen Display o GEA 24 Engine Analyzer o GSU 25 ADHARS Unit o GMU 22 Magnetometer o GAP 26 AOA/Pitot probe o Garmin GTR 200 Comm Transceiver o Garmin GTX 23ES transponder o Garmin Autopilot GSA 28 servos o 2” Airspeed and 2” Vertical Speed Indicators o Float Gear Advisory o uAvionics Skybeacon – wingtip • FLIGHT CONTROLS & INTERIOR o Dual flight controls o Elevator trim o Dual toe brakes o Pilot push-to-talk in control stick o Co-pilot push-to-talk in wing root o Pilot & co-pilot standard headset jacks in wing root o Powered ANR headset jacks in wing root (LEMO) o Adjustable front seat o Stow-away rear seat o Lap belt and inertia reel shoulder harnesses o Compass o Oregon Aero Fabric FRONT Seat o Full floorboards o Ignition Status Lights (left / right) o Symmetric Wing Landing Lights with wig-wag o Lightweight Light/Strobe PKG o Carburetor Heat Control o Mixture control o Cabin heat control o Improved Cabin Heat System o Circuit breakers o Master switch o Avionics master switch o SMARTmonitor© o 12V auxiliary outlet o Flat Black Glare Shield o Dual swing-out windows o Tinted windows and skylight o Cabin fresh air vents o Rear cabin cargo tie down points o Aft upper baggage area o Cup/Bottle holder for pilot • LANDING GEAR o AEROCET 1500 amphibious floats o Landing Gear o Cabane vee o 26” Airstreak Tundra Tires o 3200-type Steerable Tailwheel o AOSS Gear (3×3 version) • CARBON FIBER / COMPOSITES o Cowling, air filter box and spinner o Cowl flaps o Engine cooling plenum o Interior panels o Floorboards and front seat base o Pilot Seat o Wingtips o Aft upper baggage compartment • SAFETY FEATURES o Front & rear seat inertia reel 4 point harnesses o Audible stall warning horn o No header tanks o Kannad 406 Integra ELT (Built-In GPS) & Antenna o Visual fuel gauges o Halon Fire Extinguisher o Dual-action safety fuel selector valve o Complete 4130 reinforced fuselage o Ignition backup battery system o SMARTmonitor©

Recorded price changes

• 8/26/2026: $320,000
