Specifications

Description

AVIONICS Avionics: Garmin G5000 Avionics Suite Flight Displays: Four Garmin G5000 14 diagonal inch, widescreen-format Liquid Crystal Displays Synthetic Vision Technology: Garmin Synthetic Vision Technology (SVT) presents terrain & obstacle information on the PFDs in a dynamic, three-dimensional format. Touchscreen Control Panels: Four full-color, touchscreen LCD control panels provide the primary user interface with the G5000 system Automatic Flight Control System: Garmin G5000 full-featured Automatic Flight Control System (AFCS) that is integrated with the autothrottle system and includes an Emergency Descent Mode Attitude/Heading Reference System: Dual Litef LCR-100 gyrocompassing Attitude Heading Reference System Integrated Avionics Units: Dual Integrated Avionics Units include Global Positioning System (GPS) receivers, Wide Area Augmentation System (WAAS) receivers, Very High Frequency (VHF) communication radios, VHF navigation radios, and glide slope receivers. Flight Management Systems: Dual Flight Management Systems (FMS) provides extensive navigation and flight planning capabilities as well as enroute, terminal and precision and non-precision approach capabilities (including LNAV/VNAV and Localizer Performance with Vertical Guidance (LPV) approaches) Weather Radar: A Garmin GWX 70 weather radar system with a 12-inch antenna Traffic Alert and Collision Avoidance System: Garmin TCAS II system and Change 7.1 compliant Terrain Awareness Warning System: Garmin G5000 system includes Class A TAWS Transponders: Dual Mode S Diversity transponders w/ Enhanced Surveillance and ADS-B Out Standby Instrumentation: An Electronic Standby Flight Display (ESFD) provides standby airspeed, attitude, heading, altitude, and VOR/ILS navigation information Radio Altimeter: Single Radio Altimeter is included with display on the PFD and in support of TCAS II and TAWS A Cockpit Voice Recorder: Yes Emergency Locator Transmitter: Artex 406-N ELT w/ navigation interface Maintenance Diagnostic System: Yes. Includes the capability to record specific maintenance diagnostic information
